Pick Your Best 4x8 CNC Router

inquiry 1 Piece (MOQ)

Product Details



Diamond Member Since 2024Suppliers with verified business licenses

Audited SupplierAudited by an independent third-party inspection agency

Importers and ExportersThe supplier has import and export rights

Years of Export ExperienceThe export experience of the supplier is more than 10 years

Self-brandedThe supplier has 4 Self-brands, check the Audit Report for more information

Patents AwardedThe supplier had awarded 1 patents, you can check the Audit Report for more information

Find Similar Products





Brand	STYLECNC
Model	STM1325-R3
Working Area	1300x2500x200mm
Table Size	4x8 feet (48x96 inches, 1300x2500mm)
Traveling Positioning Accuracy	±0.03/300mm
Repositioning Accuracy	±0.03mm
Table Surface	Vacuum and T-slot Combined (Option: T-slot Table)
Frame	Welded Structure
X, Y Structure	Hiwin Rail Linear Bearings, Rack and Pinion Drive
Z Structure	Ball Screw, Hiwin Rail Linear Bearings
Max Power Consumption	3.0KW (Without Spindle)
Max Rapid Travel Rate	33000mm/min
Max Working Speed	25000mm/min
Spindle Power	3.0KW
Spindle Speed	0-24000RPM
Drive Motors	Stepper System
Working Voltage	AC380V/50/60Hz,3PH (Option: 220V))
Command Language	G Code
Operating System	DSP System (Options: NCstudio/Mach4 PC Software)
Computer Interface	USB
Flash Memory	128M (U Disk)
Collet	ER20
X, Y Resolution	<0.03mm
Software Compatibility	Type3/UcancameV9 Software (Option: Artcam Software)
Running Environment Temperature	0 - 45 Centigrade
Relative Humidity	30% - 75%
Packing Size	3300X2220X1800mm
N.W.	1400KG
G.W.	1680KG
Optional Parts	Air Cooling Spindle
	Dust Collector
	Vacuum Pump
	Easy servo motor
	Mist-cooling System
	Yaskawa servo motor
Price Range	$5,480.00 - $10,180.00
